CM2-RC2-M15

$1,650.00

  • 650 CFM
  • MERV 15 Filtration ~ 95% Efficient
  • 900 gram carbon / 2.5 inch filter
  • Quiet Operation
  • 24 x 24 x 13
  • 625 CADR
  • Ceiling Mounted

Description

Ceiling Mount Compact MERV 15 Smoke Eater

The CM2-RC2 Smoke Eater by LakeAir fits into a 2′ x 2′ ceiling grid. The RC2 models use dual reverse curved blowers from the famous German fan manufacturer Zeihl-Abegg  These blowers offer quiet operation with a lot of air movement. The MERV 15 Media filters are made in the USA, they are high capacity and made from anti-microbial fibers. MERV 15 filters remove 95% of particle as small as 0.3  microns. The Media filter should be replaced every 6 months to a year. These units feature an easy access door to replace the filters or service the unit.  CM2-RC2-MERV 15 is one of the lowest priced commercial smoke eaters. If you are purchasing 3 or more you expect to get an even lower price.

650 CFM was never so Quiet

One of the biggest complaints about ceiling mounted air purifiers is the amount of noise they produce. Much of this noise comes from the fan running at high rpms. One blower is enough to power the CM2 models, by adding a 2nd fan we have cut the needed motor speed in half. This reduces the amount of ambient noise greatly.  Smaller filters were needed to work in the smaller frame size. The extra blower pulls air through the smaller filters with ease.

You could turn the unit all the way up and it would be loud. Only so much air can move through the filters, so run your CM2  at half speed, and save on noise and money. About  half way between high and turbo will give you full performance with a lower ambient noise level.

External or Onboard Speed Control

The variable speed control allows you to adjust the CM2-RC2 to the exact amount of air purification and sound level desired. Customers tell us that on low and medium they don’t even hear the smoke eater running.  If you want the speed control on the unit just let us know and we will customize your unit at no extra cost.

The variable speed control can be mounted in the unit or be located in a wall switch. If the speed control is on your unit we can install a 10′ standard power cord at no extra charge.  The remote wiring is easy but requires a 6 conductor cable. The unit uses a simple 115-volt line and neutral along with 3 low voltage wires for speed control. We include complete wiring instructions and are available for any question you might have at 800-558-9436.

Flush to Ceiling or Ceiling Hung

The CM2 is a compact little unit that looks nice hanging by itself. It is equipped with 4 nut inserts and eyebolts for easy hanging. If you don’t have a drop ceiling the CM2 might still be the best fit for you. We can even set this unit up with a standard plug. just plug it into a standard outlet and your are good to go. You can even move the unit around to find the best spot in your cigar bar.

If you have more question feel free to call our customer service number 800-558-9436 or email us at [email protected]



CM2-RC2 uses

The CM2-RC2 is gaining popularity in homes with vaulted ceilings. The home air purifier can be hung out of the way not taking up precious wall or floor space. The MERV 15 filter does a great job on dust. It works perfectly as an air purifier for allergies.

CM2-RC2-M15 Specifications
Capacity 650 CFM
Filter 1 MERV 2 Pre Filter
Filter 2 16 x 12 x 4 MERV 15 filter 95% Efficient
Filter 3 2 Chamber Carbon Filter
Unit Size 24″ x 24″  x 14″
Unit Weight 50 Lbs.
Power 120 volt @ 2.6 amps
Sound 40-69 d(b)A @ 15 feet
Warranty 7 year Limited
note Does not meet California air cleaner regulation requirements: cannot be shipped to California

Additional information

Cigar-Mount

Ceiling

Cigar-#sqft

500 sq.ft

CADR

625

color

Black

Efiiciency

95% to 0.3 Micron

Filter-Frequency

12 months, 4 month, 6 month

Filter-Model

Maxum / CM2

Filter-Type

2.5 Carbon, MERV 15 Media, Pre-Filter

Filtration

Carbon, MERV 15

Mounting

Ceiling Hung, Flush to Ceiling

Odor-Control

3 ~ 2.5 / 900-1500 gram

Power

2-3 Amps

Removes

Allergens, Dust, Gases, Mold, Odors, Pet Dander, Pet Hair, Smoke, VOCs

Speed

Variable Speed Control

voltage

115 Volt

Weight

60-70 Pounds

CFM

650
